Product Overview
LDD series plstic granulator line
It is different from traditional granulation line.This LDD series smart plastic recycling pelletizing machine pays more attention to protecting the physical properties of environmental plastics, can maintain the plasticity, toughness and durability of the original environmental plastics as far as possible.
1.Suitable for the production of various waste plastics and recycled particles,such as PC,PA,PP,ABS,PE,POM,PET etc.
2.It has a high natural material composition , reduce petroleum - based raw materials and carbon dioxide emissions.
3.Excellent product performance stability,longer shelf life.
4.The output is high , and the discoloration of the product is small.
5.Electromechanical separation makes the operation easier,safer to use.
6.Both the screw and barrel adopt high strength.Made of quenched and tempered nitrided structural steel,durable.
Products Description
Product Paramenters
| Model | Screw dia.(mm) | Long dia. ratio | Output(kg/h) | Power(kw) | Rotate speed(r/min) |
| LDD-SJP-90-85 | Ø90,Ø85 | 28:1,10:1 | 100-150 | 18.5/7.5 | 10-75 |
| LDD-SJP-100-95 | Ø100,Ø95 | 28:1,10:1 | 150-200 | 30/11 | 10-75 |
| LDD-SJP-110-105 | Ø110,Ø105 | 28:1,10:1 | 200-250 | 37/11 | 10-75 |
| LDD-SJP-120-110 | Ø120,Ø110 | 28:1,10:1 | 250-300 | 45/15 | 10-75 |
| LDD-SJP-130-120 | Ø130,Ø120 | 28:1,10:1 | 300-350 | 55/15 | 10-75 |
| LDD-SJP-140-130 | Ø140,Ø130 | 28:1,10:1 | 350-400 | 75/18.5 | 10-75 |
| LDD-SJP-150-140 | Ø150,Ø140 | 28:1,10:1 | 400-450 | 90/22 | 10-75 |
| LDD-SJP-160-150 | Ø160,Ø150 | 28:1,10:1 | 450-500 | 110/30 | 10-75 |
| LDD-SJP-180-160 | Ø180,Ø160 | 28:1,10:1 | 500-600 | 132/37 | 10-75 |
Company Profile
Exhibition
|
|
Lvdao 180mm screw machine high output high quality with electromechanical separation plastic recycling machine Images
|
